TS-R700/800/900 Automatic melt (hot) side of the machine
TS-R700/800/900
This device is a thin film zipper bags of auxiliary equipment, mainly for the hot combination of two different materials, in order to give zipper bag making machine to provide material, as required Different materials to hot side, such as PE and metallized film, PE film and radium.dual discharge structure, with automatic correction, the stepper motor feeding, automatic waste blowing, sealing hot side.
| Model | TS-R700 | TS-R800 | TS-R900 |
| Forming width | 700mm | 800mm | 900mm |
| Unwinding diameter | 700mm | 800mm | 900mm |
| Winding diameter | 700mm | 900mm | 900mm |
| Welding thickness | 0.02-0.2mm | 0.02-0.2mm | 0.02-0.2mm |
| running speed | 30-100m/min | 30-100m/min | 30-100m/min |
| Power Supply | 220V-380V | 220V-380V | 220V-380V |
| Total power | 2.8kw | 3kw | 3.2kw |
| Overall dimension | 2500*1150*1100mm | 2500*1250*1100mm | 2500*1350*1100mm |
